PPA5xx/15xx user manual
5-8
5.6 Using remote control
The PPA5xx/15xx is fitted with RS232 serial
communications port and a USB port as standard and may
have LAN / GPIB interfaces fitted as an option. All the
interfaces use the same ASCII protocol with the following
end of line terminators:
carriage return
(line feed ignored)
carriage return
and line feed
All the functions of the PPA5xx/15xx can be programmed
via any of the interfaces, and results read back.
The commands are not case sensitive and white space
characters are ignored (e.g. tabs and spaces). Replies
from the PPA5xx/15xx are always upper case, delimited by
commas, without spaces.
Only the first six characters of any command are important
– any further characters will be ignored. For example, the
command to set the bandwidth is BANDWI but
BANDWIDTH may be sent as the redundant DTH at the
end will be ignored.
Fields within a command are delimited by a comma,
multiple commands can be sent on one line delimited with
a semi-colon, e.g.
BANDWI,LOW;SPEED,SLOW
Mandatory commands specified in the IEEE488.2 protocol
have been implemented, (e.g. *IDN?, *RST) and all
