9 Power measurements
In the POWER mode, the PPA5xx/15xx measures the
following values for each phase:
Parameter
Type
Units
Frequency
elementary
Hz
True power
elementary
W
Apparent power
secondary
VA
Reactive power
secondary
VAr
Power factor
secondary
RMS voltage
elementary
V
RMS current
elementary
A
Fundamental power
secondary
W
Fundamental VA
secondary
VA
Fundamental VAr
secondary
VAr
Fundamental power factor
secondary
Voltage fundamental
elementary
V
Current fundamental
elementary
A
Voltage magnitude
secondary
V
Current magnitude
secondary
A
phase
secondary
degrees
Voltage harmonic
elementary
V
Current harmonic
elementary
A
Voltage harmonic magnitude
secondary
V
Current harmonic magnitude
secondary
A
DC voltage
elementary
V
DC current
elementary
A
dc power
secondary
W
Peak voltage
elementary
V
Peak current
elementary
A
Rectified mean voltage
elementary
V
Rectified mean current
elementary
A
All elementary parameters (e.g. Watts) are computed from
their true definitions in real time so the measurements are
