Nexgrill 720 - Part List

No
.
Part (Description)
Warranty
coverage
(year)
QT
Y
No
.
Part (Description)
Warranty
coverage
(year)
QTY
1 Main lid 1 1 29 Main manifold 1 1
2 Main lid screw 1 2 30 Regulator, LP 1 1
3 Burner pin assembly 1 4 31 Pulse igniter module 1 1
4 Temperature gauge 1 1 32 Main control panel 1 1
5
Temperature gauge
Housing
1 1 33 Bezel A 1 4
6 Logo 1 1 34 Bezel B (Small) 1 1
7 Rotisserie motor bracket 1 1 35 Control knob A 1 4
8 Main lid handle seat, left 1 1 36 Control Knob B (Small) 1 1
9 Main lid handle tube 1 1 37 Grease pan 1 1
10 Main lid handle seat, right 1 1 38 Grease cup 1 1
11 Flame tamer 1 4 39 Warming rack 1 1
12 Main burner 5 4 40 Cooking grid with hole 1 2
13 Main burner igniter wire A 1 1 41 Back panel, top 1 1
14 Main burner igniter wire B 1 1 42 Side shelf, left 1 1
15 Main burner igniter wire C 1 1 43 Side shelf front panel, left 1 1
16 Main burner igniter wire D 1 1 44 Back panel, middle 1 1
17 Rotisserie heat shield 1 1 45 Back panel, bottom 1 1
18 Rear baffle 1 1 46 Side panel, left 1 1
19 Rotisserie igniter wire 1 1 47 Swivel caster with Brake 1 1
20 Rotisserie Burner 1 1 48 Swivel caster 1 1
21
Rotisserie burner orifice w/
brass elbow
1 1 49 Bottom panel 1 1
22
Rotisserie burner flex gas
line
1 1 50 Cart frame 1 1
23
Rotisserie burner igniter
bracket
1 2 51 Door magnet 1 2
24 Hood buffer 1 2 52 Triangle Bracket, left 1 1
25
Main burner bowl
assembly
Non-
replaceable
1 53 Triangle Bracket, right 1 1
26 Front baffle 1 1 54 Door iron piece 1 1
27 Main gas valve 1 4 55 Diagonal bar barrier 1 1
28 Rotisserie gas valve 1 1 56 Tank bolt 1 1
11
