Nexo NX241

PAGE 24/24
TECHNICAL SPECIFICATIONS
USER MANUAL LOAD1_80
DATE: 30/08/00 12:48
TECHNICAL SPECIFICATIONS
SPECIFICATIONS NX241 Digital TDcontroller
Output Level +28 dBu Max. into 600 Ohms load
Dynamic Range Channels 1 & 2 = 99 dBu
Channel 3 & 4 = typical 107 dBu. (Flat without gain
scaling: 101dBu)
THD + Noise < 0.02% flat setup (max0.04% for Output 27.5dBu)
Latency time 1.4ms on a flat setup
Power Supply 115/230 Volts 50/60 Hz (operating range 90-125V & 180-264V)
FEATURES
Audio Inputs 2 Audio Inputs 24 bit converters
Electronically Balanced, 36 k Ohms.
2 XLR-3F Connectors.
Sense Inputs 4 Amplifier Sense Inputs (LF mono, MF/HF L&R)
Floating 150 kΩ. 18 bit converters
8 Pole Removable Strip Terminal.
Audio Outputs 4 Audio Outputs. 24 bit converters
Electronically balanced, 50 Ohms
4 XLR-3M connectors
Processing 24 bit data with 48-bit accumulator. 100MIPS
Optional Expansion Board 300MIPS
Front Panel Menu A and Menu B buttons
16 characters by 2 lines display
Select Wheel & Enter button (!")
IN Clip – DSP Clip red LED’s
Speaker Protection yellow LED for each channel
Individual Mute/Solo buttons and red LED for each channel
Amp. Sense & Peak (green & red) LED’s for each channel
FLASH EPROM Upgrade for software improvement, new cabinet set-ups
available on NEXO web site.
Rear Panel 115/230 V switch
Fuse holder
RS232 connector for serial com.
Empty slot for extension card (communication & processing
power)
Dimensions & Weight 1U 19" Rack - 230 mm (9") Depth.
4 kg
