PARTS:
• • Pre-Assembled HOTAS Plate
37
Align the curved slots on the Pre-Assembled HOTAS Plate with the threaded inserts on the HOTAS
Swivel Bracket.
PARTS:
• • 2 x M8 16mm Sockethead Bolts
• • 2 x M8 Washers
38
Bolt through the curved slot on the Pre-Assembled HOTAS Plate and secure with 2 x M8 Bolts and
Washers.
PARTS:
• • 1 x M8 70mm Sockethead Bolts
• • 1 x M8 Washer
• • 1 x M8 Flange Nut
39
Bolt through the mounting holes on the Pre-Assembled HOTAS Plate and secure with M8 Bolt, Washer
and Flange Nut.
