NextBase DUO User Manual

PLAYBACK MODE (CONTD.)
Viewing video files
Select the required directory, press OK and the file list window will appear, as shown below.
Select video for playback using the up and down arrows and press OK to start playback.
Playback is controlled using the iN-CAR CAM buttons, as described below.
Rewind, press OK to return to normal playback
Play / pause
Stop playback and return to the file list window
Fast forward, press OK to return to normal playback
Return to main menu. Available only when playback has been stopped
Note:
- Functions and features are the same for both unprotected and protected recordings.
Playback Mode
Play
OK
1019_141097.MOV
1019_141098.MOV
1019_141099.MOV
00:03:00
22.04.2015 13:26
Menu
MENU
22/04/2015 13:26:0013:26:00
MENU
20

NextBase DUO Specifications

General

Product color	Black
Auto power off	Yes
G-shock sensor	-
Number of cameras	2
Maximum frame rate	30 fps
Aperture range (F-F)	2 - 2.2
Main camera resolution	1280 x 720 pixels
Main camera viewing angle	150 °
Video compression formats	MOV
Interior camera viewing angle	22 °
Main camera sensor resolution	1 MP
Output current	1.5 A
Battery capacity	700 mAh
Operating voltage	5 V
Power source type	Battery, Cigar lighter
Display diagonal	2 \
Built-in storage media	No
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Cables included	DC, USB
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	24 mm
Width	135 mm
Height	52 mm
Weight	95 g
