NextBase DUO User Manual

Model Number / Name
Power Requirements
Power Supply
Sensor Resolution
Wide Angle Lens (front) -
Type / Angle / Aperture
Telephoto Lens (rear) -
Type / Angle / Aperture
Recording Resolutions -
Wide Angle Lens
Zoom Lens
Dual (Wide Angle & Zoom)
Screen Size
Screen Resolution
Screen Ratio
Card Reader
SD Card
(Recommended Type)
SD Card Recorded File
Capacity
(based on default settings)
Recording Format
Video / Audio Out
Internal Battery
Unit Dimensions
Unit Weight
NBDVR-DUO / NEXTBASE iN-CAR CAM DUO
5V / 1.5A
12-24Vdc Car Power Cable (supplied)
Fuse Type: 32mm / 2A
Output: 5Vdc
1M Pixel (1,000,000 Pixel)
5G / 150° / F2.2
5G / 22° / F2.0
1280 x 720 @ 30fps
1280 x 720 @ 30fps
1920 x 800 @ 30fps (default)
2.0"
960 (W) X 240 (H) pixels x RGB
4:3
MicroSD, Class 6-10, upto 32GB
8-32GB, Class 10 (30mb/s), for best results use a recognized
brand
8GB Micro SD = 60mins of recording
16GB Micro SD = 120mins of recording
32GB Micro SD = 240mins of recording
MOV
2.5mm Jack (Video / Audio)
Lithium-ion 3.7V / 700mAh (approx. 30mins recording time)
Battery design allows the 'Auto Power Off' feature to function in
event of power loss within the vehicle. It is not intended as an
alternative power source to replace the supplied car adaptor.
135 x 52 x 24mm
95g
PRODUCT SPECIFICATION
06

NextBase DUO Specifications

General

Product color	Black
Auto power off	Yes
G-shock sensor	-
Number of cameras	2
Maximum frame rate	30 fps
Aperture range (F-F)	2 - 2.2
Main camera resolution	1280 x 720 pixels
Main camera viewing angle	150 °
Video compression formats	MOV
Interior camera viewing angle	22 °
Main camera sensor resolution	1 MP
Output current	1.5 A
Battery capacity	700 mAh
Operating voltage	5 V
Power source type	Battery, Cigar lighter
Display diagonal	2 \
Built-in storage media	No
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Cables included	DC, USB
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	24 mm
Width	135 mm
Height	52 mm
Weight	95 g
