7.3 Nexus Network error messages with cause and remedy
If an error message [Err #] is displayed, an error has been detected by the Nexus Network.
The message can assist you to diagnose the cause and remedy the error.
To escape from an error message, press any push-button. If not possible to escape, reset
power (turn off and on again), then make the remedy if suggested below.
Note! For errors marked with [*], contact your national distributor to return the unit for
rectification.
No. Message and cause Remedy *
01 Activated watchdog timeout. Reset power. *
02 Nexus Network data frames are missing. Check connections and setup.
03 No data received within approx. 10 sec. Check connections.
04 EEPROM read. Reset power. *
05 EEPROM write. Reset power. *
06 RAM memory error. Reset power. *
07 Auto-log full, in GPS Compass. Clear Auto-log memory.
08 Break reset. Reset power. *
09 EEPROM auto initiation, or NMEA
transmit fail. (Nexus Server only).
Reset power. *
10 Range error, depending on wrong input
e.g. 17° 70' = too many minutes.
Correct input format..
11 Remote control setup error. Command
can not be executed.
Check connections and settings.
12 No response from navigator. Check navigator connection and set-
tings.
13 Waypoint not defined. Define a waypoint.
14 Impossible command when used with an
external NMEA navigator.
Use only possible command.
15 Impossible command when in Autopilot
mode.
Use only possible commands.
16 Auto-deviation is not possible. Check for extreme magnetic field, up-
side down mounting of transducer or
wrong transducer type setting.
17 Auto-deviation check failed. 1¼ turn not completed or extreme
magnetic disturbance.
18 Auto-deviation. Function denied. Function denied since compass is
busy with the auto-deviation routine.
19 Auto-deviation failure.
Error larger than 1.5°. The boat
probably hit a wave during the turn.
20 GPS to CPU communication error. Reset power. *
21 GPS acquisition failure (time out). Maximum allowed time for searching
satellites. E.g. when try to navigate
indoors. Check GPS antenna loca-
tion.
22 CPU to GPS communication error. Reset power. *
23 DGPS (RTCM) data ignored. Change the DGPS (RTCM) setting.
24 GPS bad fix, no fix position (time expired
at one-fix).
Check GPS antenna location.
7 FAULT FINDING
FAULT FINDING
