Resetting the Network Configuration of the
Controller
If the controller is not able to communicate with the network, you can manually restore the
unit to the factory network settings. When you reset the controller, the IP address, subnet
mask, DNS address, gateway, and Time Server IP are set to 0.0.0.0. Resetting does not
affect power-on defaults, watchdog settings, or VIs.
Complete the following steps to reset the controller.
1. Move the IP Reset DIP switch to the ON position.
2. Push the Reset button to cycle power to the controller. The Status LED flashes once,
indicating that the controller IP address is unconfigured.
3. Move the IP Reset switch to the OFF position.
The network settings are restored. You can reconfigure the settings in MAX from a
computer on the same subnet. Refer to the Measurement & Automation Explorer Help for
more information about configuring the controller.
Note If the controller is restored to the factory network settings, the
LabVIEW run-time engine does not load. You must reconfigure the network
settings and restart the controller for the LabVIEW run-time engine to load.
cRIO-9012/9014 Specifications
The following specifications are typical for the range -40 °C to 70 °C unless otherwise noted.
Caution Do not operate the cRIO-9012/9014 in a manner not specified in this
document. Product misuse can result in a hazard. You can compromise the safety
protection built into the product if the product is damaged in any way. If the product
is damaged, return it to NI for repair.
Network
Network interface 10Base-T and 100Base-TX Ethernet
Compatibility IEEE 802.3
Communication rates 10 Mbps, 100 Mbps, auto-negotiated
Maximum cabling distance 100 m/segment
RS-232 Serial Port
Maximum baud rate 115,200 bps
Data bits 5, 6, 7, 8
Stop bits 1, 2
12 | ni.com | NI cRIO-9012/9014 User Manual and Specifications
