MTBF
The following MTBF specifications apply to the cRIO-9012/9014.
MTBF 330,481 hours at 25 °C; Bellcore Issue Level II
Power Requirements
Voltage input range
On powerup 9 V to 35 V
After powerup 6 V to 35 V
Note The cRIO-9012/9014 is guaranteed to power up when 9 V is applied to V and
C. After powerup, it can operate on as little as 6 V.
Maximum power input 20 W
Maximum power consumption
Controller only 6 W
Controller supplying power to eight
CompactRIO modules
20 W
Physical Characteristics
If you need to clean the module, wipe it with a dry towel.
Tip For two-dimensional drawings and three-dimensional models of the C Series
module and connectors, visit ni.com/dimensions and search by module number.
Screw-terminal wiring
Gauge 0.2 mm
2
to 2.1 mm
2
(24 AWG to 14 AWG)
copper conductor wire
Wire strip length 6 mm (0.24 in.) of insulation stripped from the
end
Temperature rating 85 °C
Torque for screw terminals 0.20 N · m to 0.25 N · m (1.8 lb · in. to
2.2 lb · in.)
Wires per screw terminal One wire per screw terminal
Connector securement
Securement type Screw flanges provided
Torque for screw flanges 0.3 N · m to 0.4 N · m (2.7 lb · in. to
3.5 lb · in.)
14 | ni.com | NI cRIO-9012/9014 User Manual and Specifications
