© National Instruments Corporation 13 SCC Quick Start Guide
The SC-2345 carrier and the SC-2350 carrier each have different
functionality and SCC module configurations. The following sections
cover carrier-specific information relative to SCC module installation.
SCC-SG Refer to the SCC-SG Series Strain Gage Modules User
Guide.
Blue Analog Input
SCC-TC0X
Blue Analog Input
SCC-FT01
N/A Analog Input,
Analog Output,
Digital, GPCTR
SCC-DI01
Green Digital
SCC-DO01 Green Digital
SCC-RLY01
Green Digital
SCC-CO20
Red Analog Output
SCC-AO10
Red Analog Output
SCC-CTR01
s
Yellow General Purpose
Counter/Timer
Table 2. SCC Modules: Icon, Label Color, and Measurement Type (Continued)
SCC Module Icon Label Color Measurement Type
TC
IN OUT
N.O.
COM
N.C.
3)
2)
1)
ISO
0–20mA
1)
3)
2)
ISO
±10V
+
GATE
OUT
SRC
48V ISO
400 kHz
