NI SCC Series User Manual

SCC Quick Start Guide 12 ni.com
Figure 10. SCC Module
For more information about SCC module types, accompanying icons, label
color, and measurement types, refer to Table 2.
1 SCC Screw-Terminal Receptacle
2 Label Color Stripe
3 SCC Module Name
Table 2. SCC Modules: Icon, Label Color, and Measurement Type
SCC Module Icon Label Color Measurement Type
SCC-ACC01 Blue Analog Input
SCC_AIXX Blue Analog Input
SCC-A10 Blue Analog Input
SCC-CI20 Blue Analog Input
SCC-FV01 Blue Analog Input
SCC-LPXX Blue Analog Input
SCC-RTD01 Blue Analog Input
SCC-
XXXX
1
2
3
ACC
INPUT
I
IN
V
OUT
0–100Hz
Hz
RTD
