NI SCC Series User Manual

© National Instruments Corporation 25 SCC Quick Start Guide
Step 10. Configure Channels and Tasks
This step applies only if you are programming your device using NI-DAQ
or NI application software. Refer to the Configure Channels and Tasks
seciton in the DAQ Getting Started Guide.
When using the DAQ Assistant to create a new task, refer to Table 4 for the
measurement types in NI-DAQmx and how they correspond to the SCC
modules.
For additional information about SCC-XX module-specific channel/task
settings, refer to the individual SCC-XX module user guide.
Table 4. SCC Module and Corresponding NI-DAQmx Measurement Type
SCC Module
Recommended NI-DAQmx
Measurement Type
Recommended
Parameter Settings
1
SCC-ACC01 Analog Input»Accelerometer Current Excitation Value = 4 mA,
Excitation Source = Internal
Sensitivity = #
SCC-AI01 Analog Input»Voltage Max/Min = ±42 V
SCC-AI02 Analog Input»Voltage Max/Min = ±20 V
SCC-AI03 Analog Input»Voltage Max/Min = ±10 V
SCC-AI04 Analog Input»Voltage Max/Min = ±5 V
SCC-AI05 Analog Input»Voltage Max/Min = ±1 V
SCC-AI06 Analog Input»Voltage Max/Min = ±100 mV
SCC-AI07 Analog Input»Voltage Max/Min = ±50 mV
SCC-AI13 Analog Input»Voltage Max/Min = ±10 V
SCC-AI14 Analog Input»Voltage Max/Min = ±5 V
SCC-A10 Analog Input»Voltage Max/Min = ±100 V
SCC-AO10 Analog Output»Voltage Max/Min = ±10 V
SCC-CI20 Analog Input»Current Max = 20 mA, Min = 0 mA
SCC-CO20 Analog Output»Current Max = 20 mA, Min = 0 mA
SCC-CTR01 Counter Input or
Counter
Output
Based on your application
SCC-DI01 Digital Input Use default
SCC-DO01 Digital Output Use default
SCC-FT01 Any measurement type Based on your application
SCC-FV01 Analog Input»Frequency Use default
