NI SCC Series User Manual

© National Instruments Corporation 3 SCC Quick Start Guide
• Visual C++
• Visual Basic
❑ Other tools
– 1/8 in. flathead screwdriver
– Numbers 1 and 2 Phillips screwdrivers
– Wire insulation strippers
To install NI-DAQmx, refer to the DAQ Getting Started Guide. To install
the SC-2345/2350 carrier, refer to the SC-2345/2350 Carrier User Manual.
These documents are available for at
ni.com/manuals.
Step 3. Cable the SC-2345/2350 Carrier to
the DAQ Device
Caution Refer to the Read Me First: Safety and Radio-Frequency Interference document
before removing equipment covers or connecting or disconnecting any signal wires.
Follow proper ESD precautions to ensure you are grounded before installing the hardware.
The DAQ device should already be installed in your computer. Refer to the
DAQ Getting Started Guide for installation instructions.
Connect the SC-2345/2350 carrier to the DAQ device with a 68-pin
shielded cable. If you are using an M Series DAQ device with
two connectors, connect the cable to connector 0 or 1. Use connector J24,
shown in Figure 1, on the SC-2345/2350 carrier.
