Accessories
Fuse and tariff kit for electrical supply of external electric water heater
Fuse and tariff kit components are installed in EVC 13 in the
prepared locations. Electrical connection according to the
electrical wiring diagram below. The power switch 19 is in
closed position if tariff control is not being used.
Part no. 018 973
9
20
13
31
19
8
N L1 L2 L3
N
NL1 L2 L3EXT
27
26
Supply HWH
Max 10 A
Supply cable to HWH
is connected according to the instructions
Tariff control, HWH
Room sensor
Room sensorRG 10
EVC 1328
