This part of the start guide is only displayed if the altern-
ative is selected in a previous menu and the accessory is
installed.
normal and speed 1-4
Setting range: 0 – 100 %
Set the speed for the five different selectable speeds for
the fan here.
Caution
An incorrectly set ventilation flow can damage
the house and may also increase energy con-
sumption.
12 Setting "shunt controlled add. heat"
VWDUW JXLGH
PLQLPXP UXQQLQJ WLPH
PLQ WHPS
PL[LQJ YDOYH DPSOLILHU
VWDUW DGGLWLRQ
VKXQW FRQWUROOHG DGG KHDW
KUV
r&
'0
PL[LQJ YDOYH VWHS GHOD\
VHF
This part of the start guide is only displayed if the altern-
ative is selected in a previous menu and the accessory is
installed.
start addition
Setting range: -2000 – -30 GM
Default values: -400 GM
minimum running time
Setting range: 0 – 48 h
Default value: 12 h
min temp.
Setting range: 5 – 90 °C
Default value: 55 °C
mixing valve amplifier
Setting range: 0.1 –10.0
Default value: 1.0
mixing valve step delay
Setting range: 10 – 300 s
Default values: 30 s
Set when the addition is to start, the minimum run time
and the minimum temperature for external addition with
shunt here. External addition with shunt is then for ex-
ample wood/oil/gas/pellet boiler.
For the shunt you can set shunt amplification and shunt
waiting time.
See the accessory installation instructions for function
description.
13 Setting "extra climate system"
VWDUW JXLGH
PL[LQJ YDOYH VWHS GHOD\
PL[LQJ YDOYH DPSOLILFDWLRQ
PL[LQJ YDOYH VWHS GHOD\
PL[LQJ YDOYH DPSOLILFDWLRQ
PL[LQJ YDOYH DPSOLILFDWLRQ
H[WUD FOLPDWH V\VWHP
VHF
VHF
This part of the start guide is only displayed if the altern-
ative is selected in a previous menu and the accessory is
installed.
mixing valve amplifier
Setting range: 0.1 –10.0
Default value: 1.0
mixing valve step delay
Setting range: 10 – 300 s
Default values: 30 s
Set the shunt amplification and shunt waiting time for
the different extra climate systems that are installed.
See the accessory installation instructions for function
description.
29Chapter 6 | Commissioning and adjustingNIBE™ F1145
