SYMBOLS IN THE DISPLAY
The following symbols can appear in the display during
operation.
DescriptionSymbol
This symbol appears by the information sign
if there is information in menu 3.1 that you
should note.
These two symbols indicate whether the
compressor or addition is blocked in F1345.
These can, for example, be blocked depend-
ing on which operating mode is selected in
menu 4.2, if blocking is scheduled in menu
4.9.5 or if an alarm has occurred that blocks
one of them.
Blocking the compressor.
Blocking additional heat.
This symbol appears if periodic increase or
lux mode for the hot water is activated.
This symbol indicates whether "holiday
setting" is active in 4.7.
This symbol indicates whether F1345 has
contact with NIBE Uplink.
This symbol indicates the actual speed of
the fan if the speed has changed from the
normal setting.
Accessory needed.
This symbol is visible in installations with
active solar accessories.
This symbol is displayed in menu 3.1, if pool
heating is active.
Accessory needed.
This symbol is displayed in menu 3.1, if
cooling is active.
Accessory needed.
