Connections
NOTE
To prevent interference, unscreened commu-
nication and/or sensor to external connections
cables must not be laid closer than 20 cm to
high voltage cables when cable routing.
Power connection
F2040-8
LEK
DATA
L
EK
Incoming supply
Power connection
W1
XL2
UB1
UB2
W1
XL1
UB3
NIBE™ F2040Chapter 5 | Electrical connections24
