CBOX1050
INSTALLATION AND PROGRAMMING MANUAL
12
Below is a list of tools and materials necessary for installation of the control box:
• Wire cutters/strippers
• Basic hand tools (screwdrivers, wrenches, pliers, etc..)
• Drill and assorted size bits
• Hardware for mounting control box
• Electrical conduits, grommets, asphalt patch, etc. as needed
IMPORTANT!
• The gate operator installation is NOT a “do-it-yourself” project. Contract a qualified gate operator
installation company to install this system to ensure a safe and reliable installation.
• Property owner is responsible to ensure installer is qualified to make a safe and professional installation.
• Consult local government agencies for up-to-date rules and regulations to satisfy licensing, codes or
regulations that regulate automated gate system design and installation.
• The gate being modified should be level and plumb and the gate should open easily and evenly.
• Nice swing gate systems are NOT intended for installation on an incline.
• These instructions assume actuator(s) has been installed per the applicable actuator installation manual.
Install actuator before performing the procedures in this manual.
SECTION 5: INSTALLATION SAFETY
SECTION 6: TOOLS & MATERIALS NEEDED
The following are required to power the CBOX1050 control box:
• 12VDC battery to power the control board
• An AC-to-DC fully automatic charger, a 12-30 VDC power source, and/or solar panel to charge the battery.
Nice offers AC-to-DC converters and solar panel solutions for charging 12VDC batteries. Recommended
battery specifications are as follows:
6.1 CONTROL BOX POWER REQUIREMENTS
RECOMMENDED 12VDC BATTERY SPECIFICATIONS
12 Volt DC Output
Sealed lead acid starter battery
Terminal posts on top (not sides)
35 AMP hours or larger for AC charging applications
70 AMP hours or larger for Solar charging applications & Longer Backup
NOTES: Some
purchased systems
may include a
minimum specified
12V battery as part of
the kit and a choice
of solar panel or AC
battery charger.
