CBOX1050
INSTALLATION AND PROGRAMMING MANUAL
1050 SYSTEM SPECIFICATIONS
OPEN/CLOSE TIME (TO 90°) 14 - 16 Seconds
MAX. DEGREE OF OPENING Standard install = 105°, Special install = 120°
SOLAR COMPATIBLE YES
OPERATING TEMPERATURE -4º to 122º F (-20º to 50º C)
BOX WEIGHT 19.75 lb (8.96 kg)
DIMENSIONS 8.5” x 18.25”x18.25”
PUSH-TO-OPEN INSTALLATION YES
PULL-TO-OPEN INSTALLATION YES
NUMBER OF GATES CONTROLLED Singe gate or dual gate
SENSOR TYPE INPUTS Edge, Photo Eye, and Ground Loops
DC VOLTAGE INPUT Main DC Power In: 10-35 VDC, Solar In: 10-35 VDC, 30A Max.
BATTERY POWER 12 or 24 VDC
INCLUDED SENSORS
Photo Eye TX/RX Through Beam Pair or Alternative Reective
Photo Eye
USER CONTROLS 1050 Control Board: Open, Close, Stop, Reset
ENCLOSURE CBOX: Type 3R, 18wX18hX8d (46wX46hX20.3)
ACCESSORY CONNECTORS
Power, Mag Lock, Lamp, Alarm, Loops, Edge, Exit, Guard
Station, Fire, BlueBUS
RELAYS Two programmable relays
UL 325 CERTIFICATION Usage Class I, II, III, IV
ACTUATOR SPECIFICATIONS
SPEC TYPE
1551 SYSTEM TITAN12L SYSTEM 3501 SYSTEM
816 ACTUATOR 912L ACTUATOR
3500 ARTICULATING
ARM CHASSIS
Drive Type Electromechanical Screw Electromechanical Screw
Electromechanical
Articulated Arm
Open/Close Time 14 - 16 Seconds 14 - 16 Seconds 12 - 20 seconds
Gate Max Length
and Weight
16 foot (4.9m) leaf @ up to
600 lb. (272 kg)
• 20 foot (6m) leaf @ up
to 600 lb. (272 kg)
• 8 ft (2.4 m) leaf @ up to
1000 lb (453 kg)
20 foot (6m) leaf @ up to
1000 lb (272 kg)
Actuator Lengths
(measured from
mount hole to
mount hole)
41 inches (104 cm)
retracted
67 inches (170 cm)
extended
43 inches (176.5 cm)
retracted
69.5 inches (103.3 cm)
extended
Articulating Arm Chassis
(WxHxD): 17.8 x 12 x 8.3
inches (45x30.4x21 cm)
4
