Nice HySecurity CBOX1050 - Function Button > Radio Ch.; Radio Channel Programming Options

CBOX1050
INSTALLATION AND PROGRAMMING MANUAL
40
FUNCTION>RADIO CHANNEL MENU:
For the Plug-in On board Receiver, 15 radio channels may be programmed with one of the following
options:
• No Program
• Open (Default Ch. 2)
• Close (Default Ch. 3)
• Step (Default Ch. 1)
• Partial (Default Ch. 4)
• Partial 1
• Stop
• Hold To Open
• Hold To Close
• Timer 1
• Timer 2
• Photo
• Lock
• Unlock
• Open And Lock
• Close And Lock
• Open And Unlock
• Close And Unlock
• Step H
• Togle & Latch
FUNCTION BUTTON > Radio Ch.
FUNCTION
4. Radio Ch
Radio Ch
CH1 Hold to Open
Radio Ch
ESC
Radio Ch
CH2 Togler&Latch
CH2 - CH15
Togle&Latch
Step H
Cls&Unlock
Opn&Unlock
Close&Lock
Open&Lock
Unlock
Lock
Timer 2
Timer 1
Hold to
Close
Hold to open
Stop
Paral 1
Paral
Step
Close
Open
No Program
OK
OK
OK
5. Timers
(see next page)
3. Auxiliary IO
(see previous page)
OK
OK
