English
11
This manual is for use only by technical personnel qualified to carry out the installation.
No information given in this manual can be considered of any interest to the end use!
This handbook is enclosed with items OTTO KCE and ROBO KCH, and must not be used for different products!
IMPORTANT NOTICE:
The unit described in this handbook is designed to control an electromechanical actuator for the automation of overhead swing
doors or automatic gates. Any other use is considered improper and consequently forbidden by current laws.
It is our duty to remind you that you are carrying out operations on machine systems classified in the “Automatic gates and doors”
category and as such are considered particularly “hazardous”. It is your job to make them as “Safe” as is reasonably possible!
& Only qualified, expert personnel may carry out installation and any servicing required, making the best possible job of it
and in compliance with the following Italian laws, standards or European directives:
• Decree Law No. 459/96 of 24/07/96
(EEC directive 89/392, Machine Directive)
• Decree Law No. 615/96 of 12/11/96 (EEC directive 89/336, Directive on Electromagnetic Compatibility)
• Decree Law No. 626/96 of 26/11/96 (EEC directive 93/68, Low Voltage Directive)
• DPR No. 46 of 5/03/1990 (Standards for the safety of electrical installations, authorised personnel)
• UNI 8612 standard (Motorised gates and main doors: construction criteria and protection devices against accidents)
When designing and making its products, Nice observes (as regards the equipment) all the above standards but it is of
paramount importance that the installer too (as regards the systems) continues the strict observance of the same standards.
Unqualified personnel or those who do not know the standards applicable to the “Automatic gates and doors” category:
Must under no circumstances carry out installations and systems
Whoever carries out systems without observing all the applicable standards:
Will be held responsible for any damages that the system may cause!
CONTENTS:
1 Introduction Page 12
1.1 Description “ 12
2 Installation instructions “ 12
2.1 Installation “ 13
2.2 Diagram of connections “ 13
2.3 Description of connections “ 14
2.4 Notes on connections “ 14
3 Test “ 15
3.1 Adjustments “ 16
3.2 Functioning modes “ 16
4 Programming “ 17
4.1 Programmable functions “ 17
4.2 Description of the functions “ 17
5 Maintenance “ 17
Technical features of the unit “ 18
