English
18
TECHNICAL FEATURES OF THE UNIT:
Power : 230 Vac ±20% , 50 Hz
Maximum actuator power : one
1
/2 Hp motor with capacity, max 20 µF
Maximum flashing light power : 100 W at 230 Vac (the output has a fixed voltage)
Max current accessories, 24 V : 100 mA
Gate open indicator : 24 V maximum 3W (only on ROBO)
Working time : from 2 to 120 Sec.
Pause time : from 2 to 120 Sec.
Courtesy light time : approx. 40 Sec.
Force adjustment : selectable 30,45,60,80 or 100%
Operating temperature : -20 to 70 °C
Nice s.r.l. reserves the right to modify its products at any time without prior notice.
FINAL NOTES:
This manual is for use only by technical personnel qualified to carry out the installation.
No information given in this manual can be considered of any interest to the end user!
No settings or adjustments contained in this manual can be carried out by the end user!
þ Once the plant is finished inform the end user, in detail also in writing, how to use the automatic gate, about residual
hazards and about how to use the manual unlock device in the event of a power cut.
þ Inform the owner of the plant about the need for a regular and accurate maintenance, especially regarding a regular
check of the safety and torque limiting devices.
•
•
