6- GENERAL LAYOUT AND SAFETY ACCESS
Entrapment Protection Inputs - Typical Installation Diagram Utilizing Loop Sensors and Photocells
Entrapment Protection Inputs - Typical Installation Diagram Utilizing Photocells
Loop (Safety)
Loop (Safety)
Loop (Shadow)
Loop (Exit)
4’ Min. from closed gate
4’ Min. from closed gate
4’ Min. from open gate
Photo 2 Photo 2
Outside
Gate
Outside
Gate
Photo 2 Photo 2
Photo 1
FIGURE 6 -1 LAYOUT FOR IN-GROUND LOOPS
FIGURE 6 -2 LAYOUT FOR PHOTOCELLS
1
1
