12 – English
8
DISPOSAL OF THE PRODUCT
This product is an integral part of the automation and must be scrapped with it.
Similarly to the installation operations, also at the end of this product’s working life the dismantling and scrapping operations must be performed
by qualied personnel.
This product is made up of different types of material, some of which can be recycled while others must be disposed of. Seek information on the
recycling and disposal systems envisaged by the local regulations in your area for this product category.
CAUTION! – some parts of the product may contain polluting or hazardous substances which, if disposed of into the environ-
ment, constitute serious environmental and health risks.
As indicated by the symbol, the product may not be disposed of as domestic waste. Sort the materials for disposal, according
to the methods envisaged by current legislation in your area, or return the product to the retailer when purchasing an equivalent
product.
CAUTION! – Local legislation may envisage serious nes in the event of abusive disposal of this product.
9
TECHNICAL SPECIFICATIONS
All technical specications stated in this section refer to an ambient temperature of 20°C (± 5°C). • Nice S.p.A. reserves the right to apply
modications to products at any time when deemed necessary, while maintaining the same intended use and functionality.
MODEL
TTN3724HS TTN6024HS TTN3724RHS TTN6024RHS
Motor voltage [V] 24 24 24 24
Frequency
Max gate length [m] 3,7 6 3,7 6
Max gate weight [kg] 450
Protection rating IP 54
Operating temperature [°C] -20 ... +55 -20 ... +55 -20 ... +55 -20 ... +55
Speed [cm/s] 3,2 2,7 3,2 2,7
Stroke [mm] 510 680 510 680
Nominal absorption [A] 1,5 1,5 1,5 1,5
Maximum absorption [A] 6 7 6 7
Rated power input [W] 40
Maximum power input [W] 150 170
Nominal force [N] 150 150 150 150
Maximum force [N] 1900
Work cycles (cycles/h) continuous cycle continuous cycle continuous cycle continuous cycle
Control unit MC824H MC824H MC824HR MC824HR
Motor weight [kg] 8 9 8 9
Dimensions [mm] 910 x 105 x 170 h 1080 x 105 x 170 h 910 x 105 x 170 h 1080 x 105 x 170 h
