Nidec 5200250 Step-By-Step Guide

2 Commander C200/C300 Step By Step Guide
Issue Number: 2
English
Introduction
The Commander C200 and C300 is a simple and flexible range of drives from 0.25 kW to 132 kW in 9 frame sizes
and two input voltage ranges (200 V, and 400 V).
This Step-by Step guide provides simple step-by-step instructions on how to mount the drive, fuse and cable
selection, wiring the drive-up, programming the drive and running the motor in analog input mode or keypad mode
on frames 5 to 9.
Features of the drive
Figure 1-1 Feature diagram
PE
+DC -DC
U
V
W
L1 L2 L3
6
5
5
1
41 42
2
3
4
7
7
8
9
+DC
BRAKE
8
10
11
13
7 8
9
12
5
1
2
7
U V W
5
12
12
12 12
910
8
12
1
1
2
3
13
11
4
5
6
7
6
5
Key
1. Rating label 2. Relay connections (Refer to Fig. 6-5)
3. Option module slot 1 4. Motor connections (Refer to Fig. 6-1 to Fig. 6-4)
5. Ground connections (Refer to Fig. 6-1 to 6-4) 6. AC supply connections (Refer to Fig. 6-1 to Fig. 6-4)
7. Control connections (Refer to Fig. 6-5) 8. DC bus +
9. DC bus - 10. Braking terminal
11. Cable bracket to ground terminals
12. Internal EMC filter screw
*
13. Safe Torque Off terminals (STO)**
(Refer to Fig 6-5)
* Before removing the screw, refer to Chapter 4 in the Power Installation Guide.
** Commander C300 only
