Nidec Control Techniques Unidrive M Modular User Manual

Safety information Introduction Product information System configuration
Mechanical
Installation
Electrical Installation
Unidrive M Modular Installation Guide 37
Issue Number: 2
5.5.2 Through-panel mounting
Figure 5-17 Through-panel mounting the Unidrive M size 9E/10E
n5.5 typ.
8 places
989.8
259 mm (10.20 in)
290 mm (1
1.42 in)
327 mm (12.87 in)
883 mm (34.76 in)
586 mm (23.07 in)
406 mm (15.98 in)
231 mm (9.09 in)
Æ9.0 mm (0.35 in)
x 4 holes
Æ5.5 mm (0.22 in)
x 8 holes
1051 mm (41.38 in)
863 mm (33.98 in)
566 mm (22.28 in)
386 mm (15.20 in)
211 mm (8.31 in)
31 mm
(1.22 in)
190 mm (7.48 in)
99 mm
(3.90 in)
340 mm (13.39 in)
310 mm (12.21 in)
285 mm (1
1.22 in)
1069 mm (42.09 in)
