Nidec DT-501X User Manual

13
The main display shows “0:00”.
Press the ENT key and start
setting parameters. (The main
display shows the current
set numerical value of each
parameter.)
Every time you press the key,
the display switches to the next
parameter.
Press the SET key.
The display goes to mode 3
(time wide meter mode).
0: 0 0
0: 0 0 0: 0 0
0: 0 0
0 3 - P 0 1
-
0 0 6 0. 0
-
3 6 0 0. 0
-
1 0
-
-
1 0
-
-
1
- -
0
-
Press and hold the SHIFT +
PARA keys for 5 seconds or
more to switch to the param
-
eter setting mode.
The numerical value does not need to be
changed and you can proceed to the next
step by pressing the ENT key.
(Use the key to change the numerical
value.)
The numerical value does not need to be
changed and you can proceed to the next
step by pressing the ENT key.
(Use the key to change the numerical
value.)
Use the key to move to another digit
Use the key to change the numerical value
to “60.0”.
Use the ENT key to nish setting.
Every time you press the
key, the display
switches as below.
Select "0" and use the ENT key to finish
setting.
0●1
No. Setting item Description Input range Default setting
F1 High set point 1 value
Sets the high set point 1 value (Hour:Minute:Second display system) 0:00:00 - 9:59:59
Second display system
0:00
Sets the high set point 1 value (Second display system) 0:00 - 999:99
F2 Low set point 1 value
Sets the low set point 1 value (Hour:Minute:Second display system) 0:00:00 - 9:59:59
Second display system
0:00
Sets the low set point 1 value (Second display system) 0:00 - 999:99
F3 High set point 2 value
Sets the high set point 2 value (Hour:Minute:Second display system) 0:00:00 - 9:59:59
Second display system
0:00
Sets the high set point 2 value (Second display system) 0:00 - 999:99
F4 Low set point 2 value
Sets the low set point 2 value (Hour:Minute:Second display system) 0:00:00 - 9:59:59
Second display system
0:00
Sets the low set point 2 value (Second display system) 0:00 - 999:99
F5
Hysteresis of the high and
low set point 1 values
Sets the hysteresis of the high and low set point 1 values 0 - 99 0
F6
Judgment output timer at
startup
Sets the time when the comparator judgment is output at startup 0 - 99 sec. 0 sec.
* For the description of functions, refer to pages 21 and 22.
• Start setting according to the setting example on the previous page.
Normal display
Parameter 1 setting
To the parameter settings
Parameter 2 setting
Parameter 3 setting
Parameter 4 setting
Finish setting
*If you enter a value outside the setting range, all the input values will blink, which indicates the setting is disabled.
●When this occurs, you cannot switch to other displays until you enter a value within the setting range.
Function setting item in mode 3 (Time Width Meter Mode)
(3) Function (For the setting method, refer to pages 16 and 17.)
s
t
s
s
s
s
