Nidec TNP Series User Manual

10. Importing the Data
10. 1 USB communication function
By connecting Digital Torque meter and PC by USB cable, it can have real time communication with PC
(importing of memory data or real time data acquiring of measured data.) Install the communication
software“Degitorq _ TNP” on the PC.
10. 2 The feature of Digitorq _ TNP
“Degitorq _ TNP” is add-in software of Excel, so that it can import the memory or measured data of the Digital
torque meter on the Excel sheet directly. Thanks to this, analysis and graph of frequency distribution of
imported data can be done easily.
10. 3 How to install Digitorq _ TNP
Access to the support page of our website (http://www.nidec-shimpo.co.jp/support/dl/index.html
) and
register for downloading. After registration, ID and password will be sent. With ID and Password, access to
the Download website of “Degitorq _ TNP” and get the software.
10. 4 Caution during using USB
Do not leave for long time with USB cable connected. Even if the power of Digital Torque meter is OFF, if
USB cable is connected, it drains the battery faster than usual. (if AC adaptor is connected, this may not
happen)
10 Specifications
Model
TNJ-0.5(with
output)
TNJ-2/TNP-2(with
output)
TNJ-5/TNP-5(with
output)
TNJ-10/TNP-10(with
output)
Measuring torque 0.5Nm 2Nm 5Nm 10Nm
Measuring range
0.00～±
50.00Ncm
0～±2.000Nm 0～±5.000Nm 0～±10.00Nm
Measuring unit
Ncm, mNm,
gcm, lbin
Nm, Ncm, kgcm, lbin
0 ~ 50.00 Ncm 0 ~ 2.000 Nm 0 ~ 5.000 Nm 0 ~ 10.00 Nm
0 ~ 500.0 mNm 0 ~ 200.0 Ncm 0 ~ 500.0 Ncm 0 ~ 1000 Ncm
0 ~ 5099 gcm 0 ~ 20.39 kgcm 0 ~ 50.99 kgcm 0 ~ 102.0 kgcm
Display range
0 ~ 4.425 lbin 0 ~ 17.70 lbin 0 ~ 44.25 lbin 0 ~ 88.5 lbin
0.01 Ncm 0.001 Nm 0.001 Nm 0.01 Nm
0.1 mNm 0.1 Ncm 0.1 Ncm 1 Ncm
1 gcm 0.01 kgcm 0.01 kgcm 0.1 kgcm
Display resolution
0.001 lbin 0.01 lbin 0.01 lbin 0.1 lbin
Chuck range Φ10 - 190 mm
Overload display Show "OVR" at LCD sub display, blinking LED
Main display
4-digit LCD display Character height 12mm
Sub display
3-digit LCD display Character height 7mm
Display
Judgment LED
Judgment LED(HI, GO, LO) (available with TNP series only)
Accuracy ±0.5% F.S.
Open mode
Show max value when opening (peak display)：show max torque at measuring table.
Close mode
Show max value when closing (peak display)：show max torque at measuring table.
Measuring
mode
Average mode
Real time display (average value display)：show the torque at measuring table in real
time.
Display cycle
Select from 0.125 second (8times/second), 0.25 second
(4times/second), 0.5 second (2times/second), 1 second
(8times/second). Peak display is held at 0.125 second.
Sampling range
1msec（1000 times/second）
14
