SP Series
Operating & Safety Instructions
USA – 11/14
Original instructions
42
Code
Fault
Description
Action
16
Debug Error
Error of the corresponding
digital input during PLC start
up check
Check wiring from the debug core of the
programming port.
- Reset power
17
Key switch Base Switch
Error
Error of the corresponding
digital input during PLC start
up check
Check wiring from the 'base' side of the
key switch.
- Reset power
18
Base ERROR_IO
Error on one of the inputs or
outputs of the base PLC
Check screen for further fault codes.
- Diagnose further using the service tool
19
Base ERROR_ANALOG
Error on one of the analogue
inputs to the base PLC
Check screen for further fault codes.
- Diagnose further using the service tool
20
Base
ERROR_OUTPUTBLANKING
Error on one of the safety
outputs of the base PLC
Check all connections to the relays on
the base PCB and to the elevated drive
solenoid
21
Axiomatic Valve Controller
off the CANBus
The base PLC is not receiving
the valve controller's 'present'
signal
Check the power supply to the
Axiomatic controller.
Check the CANBus connections from
the base box to the Axiomatic controller
22
Screen off the CANBus
The base PLC is not receiving
the screen's 'present' signal
Check the power supply to the screen.
Check the CANBus connections from
the basket panel to the screen
23
Joystick off the CANBus
The base PLC is not receiving
the joystick's 'present' signal
Check the power supply to the joystick.
Check the CANBus connections from
the basket panel to the joystick
24
Chassis Node off the CANBus
(Hybrid only)
The base PLC is not receiving
the chassis node's 'present'
signal
Check the power supply to the chassis
node
Check the CANBus connections from
the base box to the chassis node
Check address dials are set correctly
25
Motor / Engine Controller off
the CANBus
The base PLC is not receiving
the motor controller's 'present'
signal
Check the power supply to the motor
controller (Hybrid) or the engine node
(Diesel)
Check the CANBus connections from
the base box to the motor controller
(Hybrid) or the engine node (Diesel)
The base PLC is not receiving
the engine node 'present'
signal (Diesel)
26
Motor Controller Error
(Hybrid only)
The motor controller has
diagnosed an internal fault
Diagnose further using the service tool.
Use the LEDs on the motor controller to
ascertain the fault code(s).
(Red and Orange LEDs flash alternately)
1 red is followed by the first digit of the
code
2 reds is followed by the second digit of
the code
