Code
Fault
Description
Action
39
Links Paddle Error
Paddle analogue outputs are
not within spec of each other
Check paddle analogue voltages
Use another paddle to check inputs to
control system
40
Luffing Paddle Error
Paddle analogue outputs are
not within spec of each other
Check paddle analogue voltages
Use another paddle to check inputs to
control system
41
Slew Paddle Error
Paddle analogue outputs are
not within spec of each other
Check paddle analogue voltages
Use another paddle to check inputs to
control system
42
Telescope Paddle Error
Paddle analogue outputs are
not within spec of each other
Check paddle analogue voltages
Use another paddle to check inputs to
control system
43
Fly Paddle Error
Paddle analogue outputs are
not within spec of each other
Check paddle analogue voltages
Use another paddle to check inputs to
control system
44
Base set to Download
The base run/download switch
is set to download
Check switch is in RUN position
Check that when the switch is in RUN,
pin 24 of the PLC is 0v
45
Basket set to Download
The basket run/download
switch is set to download
Check switch is in RUN position
Check that when the switch is in RUN,
pin 24 of the PLC is 0v
46
Base ERROR_POWER
The voltage supply to the base
PLC has dropped below or is
below 10V
Check power supply to PLC
If Hybrid/Electric, check step down unit
is operational and providing 14.3v to
the control system
47
Basket ERROR_POWER
The voltage supply to the cage
PLC has dropped below or is
below 10V
Check power supply to PLC
If Hybrid/Electric, check step down unit
is operational and providing 14.3v to
the control system
48
Base ERROR_VBBR
The base PLC is not seeing any
voltage on pin 34
Check VBBr fuse in main box is OK
Check wiring to and from the fuse
49
Basket ERROR_VBBR
The basket PLC is not seeing
any voltage on pin 34
Check VBBr fuse on basket PCB is OK
Check wiring to and from the fuse
