Nikon 1 J2 User Manual

18
s
4
Attach a lens.
Be careful to prevent dust from entering the camera when the
lens or body cap is removed.
5
Turn the camera on.
Press the power switch to turn the
camera on. The power lamp will
briefly light green and the monitor
will turn on. Be sure to remove the
lens cap before shooting.
Check the battery level and number
of exposures remaining in the moni-
tor (0 15).
A
Turning the Camera Off
To turn the camera off, press the power
switch again. The monitor will turn off.
Keeping marks aligned, position lens on
camera, then rotate until it clicks into place.
Mounting mark
(camera)
Mounting mark (lens)
Mounting mark (lens)
Battery level
Exposures remaining

Nikon 1 J2 Specifications

General

Sensor Type	CMOS
Effective Pixels	10.1 million
Screen Size	3.0 inches
Lens Mount	Nikon 1 mount
Effective Angle of View	Approx. 2.7x lens focal length (35mm format equivalent)
Movie File Format	MOV
Movie Video Compression	H.264/MPEG-4 AVC
Movie Audio Recording Format	AAC
Metering Method	Matrix, Center-weighted, Spot
Shutter Type	Electronic shutter
Dimensions	106 x 61 x 29.8 mm
Sensor Size	13.2 mm x 8.8 mm
Screen Resolution	921k-dot
Video Resolution	1920 x 1080 (60i/30p), 1280 x 720 (60p)
Battery Type	EN-EL20 Rechargeable Li-ion Battery
Image Size	3872 x 2592
File Format	JPEG, NEF (RAW)
Monitor Type	TFT LCD
Exposure Modes	Program, Shutter-priority, Aperture-priority, Manual
Shutter Speed	1/16000 to 30 s
Flash Sync Speed	1/60 sec
Shooting Mode	Continuous, Self-timer
Interface	USB 2.0
HDMI Output	HDMI mini-connector (Type C)
Storage Media	SD, SDHC, SDXC
