Nikon 1 J2 User Manual

127
i
Fine-Tuning White Balance
Options other than Preset manual can be fine-tuned as follows:
1
Display fine-tuning options.
Highlight an option other than Preset
manual and press 2 to display the
fine-tuning options shown at right.
2
Fine-tune white balance.
Use the multi selector to fine-tune white balance.
3
Save changes and exit.
Press J. An asterisk will appear next to the white balance
icon (0 4) in the detailed display (0 5) to show that white
balance has been altered from default values.
Increase green
Increase blue Increase amber
Increase magenta
A
White Balance Fine Tuning
The colors on the fine-tuning axes are relative, not absolute. For
example, moving the cursor to B (blue) when a “warm” setting such
as J (incandescent) is selected will make photographs slightly
“colder” but will not actually make them blue.
Coordinates
Adjustmen
t

Nikon 1 J2 Specifications

General

Sensor Type	CMOS
Effective Pixels	10.1 million
Screen Size	3.0 inches
Lens Mount	Nikon 1 mount
Effective Angle of View	Approx. 2.7x lens focal length (35mm format equivalent)
Movie File Format	MOV
Movie Video Compression	H.264/MPEG-4 AVC
Movie Audio Recording Format	AAC
Metering Method	Matrix, Center-weighted, Spot
Shutter Type	Electronic shutter
Dimensions	106 x 61 x 29.8 mm
Sensor Size	13.2 mm x 8.8 mm
Screen Resolution	921k-dot
Video Resolution	1920 x 1080 (60i/30p), 1280 x 720 (60p)
Battery Type	EN-EL20 Rechargeable Li-ion Battery
Image Size	3872 x 2592
File Format	JPEG, NEF (RAW)
Monitor Type	TFT LCD
Exposure Modes	Program, Shutter-priority, Aperture-priority, Manual
Shutter Speed	1/16000 to 30 s
Flash Sync Speed	1/60 sec
Shooting Mode	Continuous, Self-timer
Interface	USB 2.0
HDMI Output	HDMI mini-connector (Type C)
Storage Media	SD, SDHC, SDXC
