Nikon 1 J4 Reference Manual

20
s
A
Removing Batteries and Memory Cards
After turning the camera off, confirm that
the memory card access lamp (
0 3) is off
and open the battery-chamber/memory
card slot cover. To remove the battery, first
release it by pressing the orange battery
latch in the direction shown by the arrow
and then remove the battery by hand.
To remove a memory card, first press the
card in to eject it (q); the card can then
be removed by hand (w).
Care should be
taken to prevent the card popping from
the camera when ejected.
D
Memory Cards
• Do not remove memory cards from the camera, turn the camera
off, or remove or disconnect the power source during formatting
or while data are being recorded, deleted, or copied to a com-
puter. Failure to observe these precautions could result in loss of
data or in damage to the camera or card.
• Do not touch the card terminals with your fingers or metal objects.
• Do not bend, drop, or subject to strong physical shocks.
• Do not apply force to the card casing. Failure to observe this pre-
caution could damage the card.
• Do not expose to water, heat, high levels of humidity, or direct
sunlight.
• Do not format memory cards in a computer.

Nikon 1 J4 Specifications

General

Sensor	CMOS
Sensor Size	13.2 x 8.8 mm
Image Sensor Format	CX
Image Processor	EXPEED 4A
Built-in Flash	Yes
External Flash	No
Storage Media	microSD, microSDHC, microSDXC
Connectivity	Wi-Fi
ISO Range	ISO 160-12800
Shutter Speed	1/16000 to 30 sec
Autofocus System	Hybrid AF
Number of Focus Points	171
Continuous Shooting Speed	Up to 20 fps with autofocus
Video Recording	Full HD 1080/60p
Screen	3.0 inch TFT LCD
Battery	EN-EL22 rechargeable Li-ion
Battery Life	Approx. 300 shots
Weight	Approx. 232 g with battery and memory card
