Nikon 1 J4 Reference Manual

21
s
4
Attach a lens.
Be careful to prevent dust from entering the camera when the
lens or body cap is removed. The lens generally used in this
manual for illustrative purposes is a 1 NIKKOR VR 10–30mm
f/3.5–5.6 PD-ZOOM.
Remove the
rear lens cap
Remove the camera body cap
Mounting mark (camera)
Mounting mark (lens)
Keeping the mounting marks
aligned, position the lens on
the camera

Nikon 1 J4 Specifications

General

Sensor	CMOS
Sensor Size	13.2 x 8.8 mm
Image Sensor Format	CX
Image Processor	EXPEED 4A
Built-in Flash	Yes
External Flash	No
Storage Media	microSD, microSDHC, microSDXC
Connectivity	Wi-Fi
ISO Range	ISO 160-12800
Shutter Speed	1/16000 to 30 sec
Autofocus System	Hybrid AF
Number of Focus Points	171
Continuous Shooting Speed	Up to 20 fps with autofocus
Video Recording	Full HD 1080/60p
Screen	3.0 inch TFT LCD
Battery	EN-EL22 rechargeable Li-ion
Battery Life	Approx. 300 shots
Weight	Approx. 232 g with battery and memory card
