Nikon coolpix7900 - Page 33

VAA46003-R.3659.A
- A2･ E7900 -
3rd lens group unit
① Set the 3rd lens group unit B603 and the 3rd lens group guide shaft #604 onto the CCD mount unit.
② Lubricate the 3rd lens group guide shaft #604 with the oil MZ-800S.
③ Adhere the polyester tape #694, the reflection preventive sheet #626 and the light baffle sheet #623.
#694
#604
#623
#626
B603
#626
#623
Oil: MZ-800S
