Nikon D2Hs User Manual

209
Menu Guide—The Setup Menu
Dust Off Ref Photo
This option is used to acquire reference data for the Image Dust Off function
in Nikon Capture 4 version 4.2.1 or later (available via download to purchas-
ers of Nikon Capture 4; for more information, see the Nikon Capture 4 User’s
Manual).
1
Dust Off ref photo is only available when a CPU lens is mounted on
the camera. We recommend using a lens with a focal length of at least
50 mm. If using a zoom lens, zoom in to the maximum telephoto posi-
tion.
2
Highlight Dust Off ref photo in the setup
menu ( 201) and press the multi selector to
the right. The menu shown at right will be
displayed.
3
Press the multi selector to the right. Camera
settings will be adjusted automatically. The
message shown at right will be displayed, and
will be displayed in the viewfi nder and
control panels.
Top control panel Rear control panel
Viewfi nder
To cancel the operation and return to the setup menu, press the but-
ton or press the multi selector to the left. The operation will also be
cancelled when the camera or monitor is turned off.
Image Dust Off
The Image Dust Off feature in Nikon Capture 4 version 4.2.1 or later processes NEF
(RAW) photographs to remove the effects of dust in the camera imaging system by
comparing the images to the data acquired with Dust Off ref photo. It is not avail-
able with TIFF (RGB) or JPEG images. The same reference data can be used for NEF
(RAW) photographs taken with different lenses or at different apertures.

Nikon D2Hs Specifications

General

Megapixel	4.1 MP
Sensor type	CCD
Metering	3D Matrix II
Interface	USB 2.0 (Hi-Speed) (Mini-B); FTP + Wireless Transmitter WT-2A, WT-1A .
Minimum RAM	64 MB
Power source	EH-6, MH-21, EN-EL4
Built-in flash	Yes
Camera shutter speed	1/250 s
Minimum storage drive space	60 MB
Minimum system requirements	CD-ROM Display: 800 x 600
Compatible operating systems	Mac(R)OS X (10.1.5) Windows XP Home Edition/Professional, Windows 2000 Professional, Windows ME, Windows 98SE
Viewfinder type	Optical
Compatible memory cards	cf, microdrive
Display diagonal	2.5 \
Display resolution (numeric)	232.000 pixels
I/O ports	DC in; Audio/Video (NTSC / PAL selectable) out; Digital I/O (USB).
Bundled software	PictureProject 1.5 4.2.1
Self-timer delay	2, 10 s
Product color	Black
Battery type	EN-EL4
Power requirements	11.1V
Flash modes	Red-eye reduction
Focus adjustment	Auto

Weight and Dimensions

Depth	85.5 mm
Width	157.5 mm
Height	149.5 mm
Weight	1070 g
