Nikon D2X User Manual

129
Taking Photographs—Non-CPU Lenses
2
Highlight Focal length and press the multi
selector to the right.
3
Select the group to which the lens belongs
from 6 - 45, 50 - 180, 200 - 4000 and press the
multi selector to the right.
4
Select the lens focal length (in mm) and press
the multi selector to the right.
Default Maximum Aperture
Selecting a focal length sets Maximum aperture to the last value selected at that
focal length.
The FUNC. Button
1
Select FV Lock/Lens data for Custom Setting
f4 (FUNC. Button; 205).
2
Press the FUNC. button and rotate the main
command dial. Focal length is displayed in the
top control panel:
…

Nikon D2X Specifications

General

Megapixel	12.84 MP
Sensor type	CMOS
Maximum image resolution	4288 x 2848 pixels
Metering	3D Color Matrix
Interface	USB 2.0, Wireless Transmitter WT-1/1A (IEEE 802.11b) & WT-2/2A (IEEE 802.11b/g), CF card Type II+
Photo mode	Continuous High [CH] Full image 5 fps / Continuous High [CH] High speed cropped image 8 fps / Continuous Low [CL] Full image - 1 ~ 4 fps / Continuous Low [CL] High speed cropped image - 1 ~ 7 fps / Self-Timer / Buffer size / Interval timer
Minimum RAM	64 MB
Power source	EH-6 / EN-EL4
Built-in flash	Yes
Camera shutter speed	30 ~ 1/8000 s
Minimum storage drive space	60 MB
Minimum system requirements	Display: 800 x 600 CD-ROM
Compatible operating systems	Mac(R)OS X (10.1.5) Windows(R) XP Home Edition/Professional, Windows(R) 2000 Professional, Windows(R) ME, Windows(R) 98SE
Viewfinder type	Optical
Compatible memory cards	cf, microdrive
Display diagonal	2.5 \
Display resolution (numeric)	235.000 pixels
I/O ports	USB Wireless Transmitter WT-1/1A
Bundled software	Nikon Capture 4
Self-timer delay	2, 10 s
Product color	Black
Battery type	EN-EL4
Power requirements	11.1V
Flash modes	Red-eye reduction
Focus adjustment	Auto

Weight and Dimensions

Depth	85.5 mm
Width	157.5 mm
Height	149.5 mm
Weight	1070 g
