Nikon D2X User Manual

249
Technical Notes—Caring for the Camera
Caring for the Camera
Storage and Maintenance
Storage
When the camera will not be used for an extended period, replace the mon-
i tor cover, remove the battery, and store the battery in a cool, dry area with
the terminal cover in place. To pre vent mold or mil dew, store the cam era in a
dry, well-ven ti lat ed area. Do not store your cam era with naph tha or cam phor
moth balls or in lo ca tions that:
• are poorly ventilated or damp
• are next to equipment that produces strong elec tro mag net ic fi elds, such as
televisions or radios
• are exposed to temperatures above 50 °C/122 °F (for example, near a
space heater or in a closed ve hi cle on a hot day) or below –10 °C (14 °F)
• are subject to humidities of over 60%
See “Caring for the Camera and Battery” (
iv–v) for more information.
Cleaning
Camera
body
Use a blower to remove dust and lint, then wipe gently with a soft,
dry cloth. After using the camera at the beach or seaside, wipe off
sand or salt with a cloth lightly dampened in distilled water and dry
thor ough ly.
Lens,
mirror, and
viewfi nder
These elements are made of glass and are easily dam aged. Remove
dust and lint with a blower. If using an aerosol blower, keep the can
vertical to prevent the discharge of liquid. To remove fi ngerprints and
other stains, apply a small amount of lens cleaner to a soft cloth and
clean with care.
Monitor
Remove dust and lint with a blower. When removing fi ngerprints and
other stains, wipe the surface lightly with a soft cloth or chamois leath er.
Do not apply pressure, as this could result in damage or malfunction.
Ambient
light sensor
Use a blower to remove dust and lint, then wipe gently with a soft, dry
cloth. Do not use alcohol or lens cleaning solutions.
The Monitor
Should the monitor break, care should be taken to avoid injury caused by broken glass
and to prevent liquid crystal from entering your eyes and mouth.
The Control Panel
Rarely, static electricity may cause the control panel to brighten or darken. This does
not indicate a malfunction; the display will shortly return to normal.

Nikon D2X Specifications

General

Megapixel	12.84 MP
Sensor type	CMOS
Maximum image resolution	4288 x 2848 pixels
Metering	3D Color Matrix
Interface	USB 2.0, Wireless Transmitter WT-1/1A (IEEE 802.11b) & WT-2/2A (IEEE 802.11b/g), CF card Type II+
Photo mode	Continuous High [CH] Full image 5 fps / Continuous High [CH] High speed cropped image 8 fps / Continuous Low [CL] Full image - 1 ~ 4 fps / Continuous Low [CL] High speed cropped image - 1 ~ 7 fps / Self-Timer / Buffer size / Interval timer
Minimum RAM	64 MB
Power source	EH-6 / EN-EL4
Built-in flash	Yes
Camera shutter speed	30 ~ 1/8000 s
Minimum storage drive space	60 MB
Minimum system requirements	Display: 800 x 600 CD-ROM
Compatible operating systems	Mac(R)OS X (10.1.5) Windows(R) XP Home Edition/Professional, Windows(R) 2000 Professional, Windows(R) ME, Windows(R) 98SE
Viewfinder type	Optical
Compatible memory cards	cf, microdrive
Display diagonal	2.5 \
Display resolution (numeric)	235.000 pixels
I/O ports	USB Wireless Transmitter WT-1/1A
Bundled software	Nikon Capture 4
Self-timer delay	2, 10 s
Product color	Black
Battery type	EN-EL4
Power requirements	11.1V
Flash modes	Red-eye reduction
Focus adjustment	Auto

Weight and Dimensions

Depth	85.5 mm
Width	157.5 mm
Height	149.5 mm
Weight	1070 g
