Nikon D2X User Manual

130
Taking Photographs—Non-CPU Lenses
Specifying Maximum Aperture
Lens maximum aperture can be specifi ed using the Non-CPU lens data op-
tion in the shooting menu or by pressing the FUNC. button and rotating the
sub-command dial. The following f/-numbers are available:
• 1.2, 1.4, 1.8, 2, 2.5, 2.8, 3.3, 3.5, 4, 4.5, 5, 5.6, 6.3, 7.1, 8, 9.5, 11, 13,15,
16, 19, 22
The Non-CPU Lens Data Menu
1
Highlight Non-CPU lens data in the shooting
menu ( 166) and press the multi selector to
the right.
2
Highlight Maximum aperture and press the
multi selector to the right.
3
Select the f/-number corresponding to the
maximum lens aperture and press the multi
selector to the right.
SB-8 00 / SB-6 00
If an SB-800 or SB-600 Speedlight is mounted on the camera, turn the Speedlight off
before using the FUNC. button to specify lens data.
Zoom Lenses
Lens data are not adjusted when non-CPU lenses are zoomed in or out. After changing
the zoom position, select new values for lens focal length and maximum aperture.

Nikon D2X Specifications

General

Megapixel	12.84 MP
Sensor type	CMOS
Maximum image resolution	4288 x 2848 pixels
Metering	3D Color Matrix
Interface	USB 2.0, Wireless Transmitter WT-1/1A (IEEE 802.11b) & WT-2/2A (IEEE 802.11b/g), CF card Type II+
Photo mode	Continuous High [CH] Full image 5 fps / Continuous High [CH] High speed cropped image 8 fps / Continuous Low [CL] Full image - 1 ~ 4 fps / Continuous Low [CL] High speed cropped image - 1 ~ 7 fps / Self-Timer / Buffer size / Interval timer
Minimum RAM	64 MB
Power source	EH-6 / EN-EL4
Built-in flash	Yes
Camera shutter speed	30 ~ 1/8000 s
Minimum storage drive space	60 MB
Minimum system requirements	Display: 800 x 600 CD-ROM
Compatible operating systems	Mac(R)OS X (10.1.5) Windows(R) XP Home Edition/Professional, Windows(R) 2000 Professional, Windows(R) ME, Windows(R) 98SE
Viewfinder type	Optical
Compatible memory cards	cf, microdrive
Display diagonal	2.5 \
Display resolution (numeric)	235.000 pixels
I/O ports	USB Wireless Transmitter WT-1/1A
Bundled software	Nikon Capture 4
Self-timer delay	2, 10 s
Product color	Black
Battery type	EN-EL4
Power requirements	11.1V
Flash modes	Red-eye reduction
Focus adjustment	Auto

Weight and Dimensions

Depth	85.5 mm
Width	157.5 mm
Height	149.5 mm
Weight	1070 g
