Nikon D2X User Manual

167
Menu Guide—The Shooting Menu
Shooting Menu Bank
All shooting menu options except interval timer and multiple exposure set-
tings are stored in one of four banks. Changes to settings in one bank have
no effect on the others. To store a particular combination of frequently-used
settings, select one of the four banks and set the camera to these settings.
The new settings will be stored in the bank even when the camera is turned
off, and will be restored the next time the bank is selected. Different com-
binations of settings can be stored in the other banks, allowing the user to
switch instantly from one combination to another by selecting the appropri-
ate bank from the bank menu.
The default names for the four shooting menu banks are A, B, C, and D. A
descriptive caption can be added using the Rename option.
To display the bank menu, highlight Shooting
menu bank in the shooting menu (
166) and
press the multi selector to the right. Press the
multi selector up or down to highlight an option,
then press to the right to make a selection.
Option Description
A
*
(default)
Select bank A.
B
*
Select bank B.
C
*
Select bank C.
D
*
Select bank D.
Rename Rename selected bank.
* Descriptive caption will also be displayed if bank has been renamed.
Sensitivity (ISO Equivalency)
If a bank in which ISO has been set to HI-1 or HI-2 is chosen after On is selected for
Custom Setting b1 (ISO auto; 188), sensitivity (ISO equivalency) will NOT be adjusted
automatically.
Shooting Menu Bank
The rear control panel shows the bank currently selected
in the shooting menu bank menu.

Nikon D2X Specifications

General

Megapixel	12.84 MP
Sensor type	CMOS
Maximum image resolution	4288 x 2848 pixels
Metering	3D Color Matrix
Interface	USB 2.0, Wireless Transmitter WT-1/1A (IEEE 802.11b) & WT-2/2A (IEEE 802.11b/g), CF card Type II+
Photo mode	Continuous High [CH] Full image 5 fps / Continuous High [CH] High speed cropped image 8 fps / Continuous Low [CL] Full image - 1 ~ 4 fps / Continuous Low [CL] High speed cropped image - 1 ~ 7 fps / Self-Timer / Buffer size / Interval timer
Minimum RAM	64 MB
Power source	EH-6 / EN-EL4
Built-in flash	Yes
Camera shutter speed	30 ~ 1/8000 s
Minimum storage drive space	60 MB
Minimum system requirements	Display: 800 x 600 CD-ROM
Compatible operating systems	Mac(R)OS X (10.1.5) Windows(R) XP Home Edition/Professional, Windows(R) 2000 Professional, Windows(R) ME, Windows(R) 98SE
Viewfinder type	Optical
Compatible memory cards	cf, microdrive
Display diagonal	2.5 \
Display resolution (numeric)	235.000 pixels
I/O ports	USB Wireless Transmitter WT-1/1A
Bundled software	Nikon Capture 4
Self-timer delay	2, 10 s
Product color	Black
Battery type	EN-EL4
Power requirements	11.1V
Flash modes	Red-eye reduction
Focus adjustment	Auto

Weight and Dimensions

Depth	85.5 mm
Width	157.5 mm
Height	149.5 mm
Weight	1070 g
