Nikon D700 - Discharge of Main Condenser; DG Shield Plate Unit

VBA22001-R.3754.A
-D12 ･ D700-
Discharge of Main condenser
・
Discharge the main condenser (#5067).
Be careful NOT to touch the body during discharging.
2KΩ/5W
Main condenser (#5067)
・
Take out the ve screws (#1521), and remove the shield plate unit (#B683).
Shield plate unit (#B683)
DG shield plate unit
INC
