Measuring between the current point and the immediately
preceding point
2: Radial
Measuring between the current point and the first point
measured
The screen shown right appears by
selecting 1 or 2 in the RDM menu. Sight
the 1st point and press the [MSR] or
[TRK] key.
The distance from the station point to the
1st point is displayed.
Sight the 2nd point and press the [MSR]
or [TRK] key. The distances between the
1st and 2nd point are displayed.
rSD : Slope distance between two points.
rVD : Vertical distance between two points
rHD : Horizontal distance between two points
Press the [DSP] key to change data
displays.
rHA : Azimuth from 1st point to 2nd point
rV% : Percentage of grade (rVD/rHD) x 100%
rGD : Vertical grade (rHD/rVD) : 1
ｒＳＤ： １５．６７３５ｍ
ｒＶＤ： ２．５８１０ｍ
ｒＨＤ： １５．４２７１ｍ
ＲＤＭ１／２
ｒＳＤ： ｍ
ｒＶＤ： ｍ
ｒＨＤ： ｍ
ＲＤＭ１／２
ｒＳＤ： ５５．３６５１ｍ
ｒＶＤ： ５．４２１２ｍ
ｒＨＤ： ５０．２６８７ｍ
ＲＤＭ１／２
ｒＨＡ：３５０°２６’５０”
ｒＶ％： １０．７４％
ｒＧＤ： １５ ．１６０：１
ＲＤＭ２／２
