Ш
2.
P-CQ
Quartz
wedge
The
P-CQ
quartz
wedge
is
used
by
inserting
it
into
the
slot
of
the
intermediate
tube
in
place
of
the
P-CL
1/42
&
tint
plate.
The
quartz
wedge
is
engraved
with
a
scale
and
can
be
used
for
rough
measurement
of
retardation
in
the
range
of
12-62.
It
is
normal
to
bring
the
top
lens
of
the
condenser
into
the
optical
path
when
observing
at
a
magnification
of
10x
or
greater.
Measuring
the
retardation
or
evaluating
by
interference
color,
however.
swing
out
the
top
lens
even
for
a
magnification
of
10x
stop
down
the
condenser
aperture
diaphragm
or
higher
(with
the
aperture
diaphragm
fully
opened),
and
illuminate
with
light
that
is
as
parallel
to
the
optical
axis
as
possible.
1
Determination
of
Extinction
Position
Rotate
the
stage
with
the
specimen
under
the
crossed
Nicols
to
find
the
direction
where
part
of
the
specimen
to
be
measured
appears
darkest.
2
Determination
of
Subtraction
Position
Rotate
the
stage
45?
from
the
extinction
position
to
the
diagonal
position
(direction
whe
the
specimen
appears
brightest).
Insert
the
P-CQ
quartz
wedge
into
the
slot
of
the
intermediate
tube
and
confirm
that
the
interference
color
of
the
section
of
the
specimen
measured
changes
toward
the
lower
order
side.
If
the
interference
color
changes
toward
higher
order
side,
rotate
the
stage
another
90%
3
Measurement
Move
the
section
of
the
specimen
to
be
measured
to
the
center
of
the
crosshairs
of
the
eyepiece.
Next,
slide
the
P-CQ
quartz
wedge
along
the
slot
and
observe
that
the
interference
color
sequentially
changes.
Stop
sliding
the
quartz
wedge
where
the
dark
stripe
covers
the
section
of
the
specimen
to
be
mi
from
the
q
asured.
Reading
the
value
artz
wedge
scale
at
that
time
can
make
rough
measurement
of
retardation
Retardation
can
be
measured
even
more
curately
by
using
the
P-CS
Sénarmont
compensator
in
combination
with
the
P-CQ
quartz
wedge.
Read
the
scale
26
