Review of the menus
Menus in the CTS 600 control
CTS 600 control has 12 menus.
The control will have the main menu as starting point, (the menu in the full-drawn frame). From
here it is possible to go through the other menus via pq.
Allows for a low ventilation level at a low outside air temperature.
Main menu: displays operating status.
Press ESC to return to the main menu.
Operating mode (heat, auto, cool), temperatures, fan speed, type of unit and
software version.
Alarm display and reset.
Alarm log containing the latest 16 alarms.
SHOW
ALARMS
Page 10
SHOW
Page 13
AUTO W/1
>2< 19°C
Page 9
USER
Page
14
Options: exhaust, inlet, ventilation, OFF. The function selected is activated via a
switch or pressure.
15
Page
10-09-13
TM.. 12:10
Date and time settings. The time and date must be reset if the system has been
without power for more than 24 hours. Summer and winter time must also be set
manually.
Page
16
Weekly program can be set to ON or OFF. When the program is active, 1, 2
or 3 is displayed in the main menu.
SELECT
WEEK
PROGRAM
COOLING
Page 19
Enables you to choose a higher ventilation level when the system is cooling
by means of an open bypass damper.
Page 20
Page 21
Page 22
Page 23
AIR
EXCHANGE
AIR
FILTER
TEMP.
CONTROL
LANGUAGE
ENGLISH
The controls are factory set to activate a filter alarm every 90 days. The alarm
is reset in the VIEW ALARMS menu.
Enables you to set the minimum temperature allowing for the bypass damper
to close. Maximum injection temperature can be set for a heating element.
Select the required language: English, German, French, Swedish,
Danish, Norwegian, Finnish, Czech
HEATING
Page 18
The system has a heating surface installed. The heating surface can be
chosen ON/OFF. Frost-protection is still active when OFF is chosen.
SURFACE
DATA
