ENGLISH INSTRUCTIONS FOR USE
6 SC250, Scrubtec 334 - 9100001614
TECHNICAL DATA
Model SC250, Scrubtec 334
Solution and recovery water tank capacity 6 litres / 6 litres
Machine size (length x width x height) 630 x 425 x 400 mm
Cleaning width 340 mm
Squeegee width
360 mm
Rear rotating wheel diameter
75 mm
Front wheel diameter
50 mm
Cylindrical brush diameter 80 mm
Brush pressure on the ground Max. 12 Kg
Min/max solution ow 0.15 / 0.3 L/min
Sound pressure level at workstation (ISO 11201, ISO 4871, EN 60335-2-72) (LpA) 66 dB(A) ± 3 dB(A)
Machine sound power level (ISO 3744, ISO 4871, EN 60335-2-72) (LwA) 83 dB(A)
Vibration level at the operator’s arms (ISO 5349-1, EN 60335-2-72) < 2.5 m/s
2
Maximum gradient when working 2 %
Vacuum system motor power 180 W
Vacuum system capacity 650 mm H
2
O
Brush motor power 180 W
Brush rotation speed 1,000 rpm
Total power draw (EN 60335-2-72) 0.3 kW
IP protection class X4
Protection class (electric) III
Electrical system voltage 36 Vdc
Standard battery Lithium Ion - 36 Vdc 8Ah
Battery charger output 42 Vdc 1÷2 A
Operating time (EN 60335-2-72) 40 min
Weight with empty tanks 25 Kg
Gross vehicle weight (GVW) 32 Kg
Shipping weight 30 Kg
MACHINE DESCRIPTION
MACHINE STRUCTURE
1. Handlebar with control panel
2. Start/stop switch
3. Solution switch:
• 1 LED on - normal cleaning with low solution ow
• 2 LEDs on - cleaning with maximum solution ow
• 2 LEDs ashing - solution tank empty
• LEDs off - solution deactivated
4. Vacuum system push-button:
• LED on - vacuum system activated
5. Battery charging symbol
• 1 - 6 LEDs on - battery charge percentage
• 1 LED on - battery almost at (~ 10 min. remaining)
• 1 LED ashing - battery at (~ 5 min. remaining)
6. Grip handles with operator palm sensors
7. Front squeegee lifting lever
8. Handlebar inclination adjustment lever
9. Function block push-buttons:
A) Front squeegee lifted
B) Handlebar free angle
10. Park pedal:
• Lowered - parking/movement
• Raised - scrubbing/drying
11. Parking/handling front wheel
12. Recovery tank cover
13. Tanks (solution and recovery water) container
14. Solution tank ller plug
15. Tanks container lifting handle
16. Machine body/cleaning deck
17. Brush engagement/disengagement lever
18. Cylindrical brush
19. Brush oor pressure regulation knob
20. Squeegee bars
21. Debris collection tray
22. Brush drive belt compartment
23. Rear pivoting wheels
24. Folded handlebar
25. Transport handle
26. Battery and electronics compartment cover
27. Battery
28. Battery charger tray
29. Socket for battery charger
30. Serial number plate/technical data/conformity certication
