A-28 / ENGLISH
A-28 - FORM NO. 56041980 - CS7000
LUBRICATING THE MACHINE – FIGURE 11
Once a month, pump a small amount of grease into each grease f tting on the machine until grease seeps out around the bearings.
Grease fi tting locations (or apply grease to) (DE):
• Squeegee Caster Wheel Axle and Pivot
• Steering Gears – requires specif c grease (Nilf sk-Advance PN 56510412) Chevron Open Gear Lube 250 NC.
Once a month, apply light machine oil to lubricate the (DF):
• Squeegee tool end wheels
• Fuel Tank Cover Latch (LPG and Diesel only)
• Recovery Tank Latch
• Brake Pedal (parking brake) linkage
FIGURE 11
