Nilfisk-Advance E130.3 User Manual

12
D
Service / Repair.
Fig. 10
Disassembly / assembly of the motor/pump unit.
1. Remove all wires from the motor - wires can stay on the switch (Fig 10)
2. Remove 8 TORX 20 screws. (Fig 11) The structural front can now be removed without
dismounting the capacitor and power cable. (see next page)
Fig. 11
