16
D
Service / Repair.
Disassembly / assembly of the hose reel.- X-TRA models.
Remove the telescopic handle by removing the 4 TORX 20 screws (Fig 18)
1. Loosen the hose reel by removing the 2 TORX 20 screws from the back side. (Fig 19)
The hose reel can be dismounted from the cabinet.
Fig. 19
Fig. 18
