Nilfisk-Advance SC4000

A - 48 Advance SC4000 - 56091272 9/2022
INSTRUCTIONS FOR USEA - ENGLISH
TECHNICAL SPECIFICATIONS
(AS INSTALLED AND TESTED ON THE UNIT)
Model SC4000 28D
SC4000 28D HP
SC4000 34D
SC4000 34D HP
SC4000 28 REV
SC4000 28 REV HP
Model No.
56120071
56120406
56120074
56120409
56120072
56120407
Voltage, Batteries V
36
36 36
Battery Capacity (max) Ah C20
240
240 240
Protection Grade, Operating
Class 3
Class 3 Class 3
Protection Grade, Charging
Class 1
Class 1 Class 1
Sound Pressure Level
IEC 60335-2-72: 2002 Amend. 1:2005, ISO 11203, ISO 3744
dB(A)/20μPa 65.8
67.8 65.5
Sound Pressure level - KpA
(IEC 60335-2-72, ISO 11203) Uncertainty
dB(A) 3.0
3.0 3.0
Gross Vehicle Weight* lbs / kg
1662 / 754
1673 / 759 1660 / 753
Transportation Weight**
lbs / kg 1250 / 567
1261 / 572 1250 / 567
Maximum Wheel Floor Loading (center front) psi / kg/cm
2
149.6 / 10.5 154.2 / 10.8 142.4 / 10.0
Maximum Wheel Floor Loading (right rear) psi / kg/cm
2
95.5 / 6.7 95.9 / 6.7 97.9 / 6.9
Maximum Wheel Floor Loading (left rear) psi / kg/cm
2
103.9 / 7.3 103.0 / 7.2 106.0 / 7.5
Vibrations at the Hand Controls (ISO 5349-1) m/s
2
0.395
0.395 0.638
Vibrations at the Seat (EN 1032)
m/s
2
0.256
0.256 0.107
Gradeability Transport* % ( °)
16 / 9 16 / 9 16 / 9
Gradeability Cleaning* % ( °)
9 / 5 9 / 5 9 / 5
Machine Length inch / cm
62.6 / 159
Machine Height inch / cm
57.7 / 146
Machine Width inch / cm
31.1 / 79.2 36.2 / 92.0 31.1 / 79.2
Machine Width with Squeegee inch / cm
32.7 / 83.3 41.5 / 105.5 32.7 / 83.3
Minimum Aisle Turn Width inch / cm
65.5 / 166.3 68.5 / 174.0 65.5 / 166.3
Solution Tank Capacity Gallon / L
33 / 125
Recovery Tank Capacity Gallon / L
33 / 125
Transport Speed Std (Fwd. Maximum) mph / kph
4.35 / 7.0
Transport Speed Std (Rev. Maximum) mph / kph
3.0 / 4.8
Transport Speed HP (Fwd. Maximum) mph / kph
5.0 / 8.0
Transport Speed HP (Rev. Maximum) mph / kph
3.0 / 4.8
Battery Compartment Size (approximate)
Height (maximum) inch / cm
17.3 / 440
Width (maximum) inch / cm
16.3 / 415
Length (maximum) inch / cm
23.8 / 605
Scrub brush size
Brush Diameter - Disc
(Quantity of 2)
inch / cm
Ø 14.0 / 35.5 Ø 17.0 / 43.2 Ø 14.0 / 35.5
Scrub Brush Speed RPM
250 250 2200 (motor RPM)
Cleaning Path Width (scrubbing path) inch / cm
27.2 / 69.1 33.2 / 84.3 27.2 / 69.1
*Gross Vehicle Weight: Standard machine without options, full solution tank and empty recovery tank, with removable scrub brushes, batteries installed and 165 lb /
75 kg operator.
**Transportation Weight: Standard machine without options, empty solution and recovery tanks, with batteries installed and no operator.
revised 1/2023
